Self Drilling Screws
A self-drilling screw is a hardened fastener featuring an integral drill point at its tip, designed to drill, tap, and fasten in a single operation—eliminating the need for a pre-drilled pilot hole. This "three-in-one" capability makes it the most efficient solution for joining metal-to-metal, metal-to-wood, and metal-to-composite applications in high-volume construction and industrial fabrication.
Product Name:
Self-Drilling Screw (Tek Screw)Material:
Carbon steel (case-hardened), Alloy Steel, Stainless Steel (SS410, SS304/SS316)Surface Finish:
Zinc plating (yellow zinc, blue-white zinc), Ruspert coating, Dacromet, Ceramic Coating, Black Oxide, Phosphating, Plain; Passivation for stainless steelSize:
Gauge #6–#14; Metric equivalents approx. 3.5 mm–6.3 mmThread Type:
Coarse or Fine Thread; Fully threaded or Partially threadedHead Type:
Hex washer head, Pan, Flat/Countersunk, Truss, Wafer head, Bugle, with optional integrated/bonded washer or EPDM sealing washerDrive Type:
Hex (external), Phillips, Pozidriv, Square (Robertson), Torx/Star, CombinationLength Range:
Approx. 13 mm – 150 mm (1/2″ – 6″); longer sizes available on requestDrill Point Number:
Self-drilling point #1–#5 — the point number indicates drilling capacity (metal thickness it can drill through without a pilot hole); higher numbers drill thicker steelSuitable Material:
Metal-to-metal, metal-to-wood; steel sheet/sections, light-gauge structural steel, sheet metal, HVAC ducting; drilling capacity depends on point typeApplicable Standards:
ASTM C1513, SAE J78, ISO 15480 / 15481 / 15482, DIN 7504, GB 3098.11, plus ETA/structural approvalsApplication:
Steel framing and metal building construction, roofing and cladding, HVAC and ductwork, sheet-metal fabrication, automotive, solar mounting, general metalworkCustomization:
Customizable material, size, length, head type, drive type, coating, drill point capacity, sealing washer, logo marking (OEM/ODM), and packaging
Send Inquiry
Product Description
A self-drilling screw is a hardened fastener featuring an integral drill point at its tip, designed to drill, tap, and fasten in a single operation—eliminating the need for a pre-drilled pilot hole. This "three-in-one" capability makes it the most efficient solution for joining metal-to-metal, metal-to-wood, and metal-to-composite applications in high-volume construction and industrial fabrication.
Hot Tags: Self Drilling Screw
